This 0.96-inch TFT LCD display features a 128×64 resolution, providing clear and compact visual output for small embedded applications. It uses LED backlight with 150 cd/m² brightness and supports SPI 4-wire interface for simple and efficient communication. Equipped with the ST7735S driver IC, it ensures stable performance and wide compatibility. With a compact design and operating temperature range of -20°C to 70°C, this display is ideal for wearable devices, portable instruments, and low-power
0.96 Inch 128x64 Full Color LCD Display Module with 35ms Response Time and 26.70 W *19.26 H *1.5 T Dimensions
| Size | 0.96 inches |
| Resolution | 128*64 |
| Backlight Type | LED |
| Viewing Angle | 12 O'CLOCK |
| Brightness | 150cd/m2 |
| Interface | SPI 4W |
| Driving IC | ST7735S |
| Operating temperature | -20℃~70℃ |
| NO. | Symbol | Level | Function |
| 1-5 | NC | Not Connection. | |
| 6 | LEDA | Power supply for backlight anode input terminals. | |
| 7 | VCC | 2.8V | Power supply |
| 8 | GND | Ground. | |
| 9 | IOVCC | 1.8V | Power supply for /O system. |
| 10-12 | NC | Not Connection. | |
| 13 | CS | Serial communication chip select. | |
| 14 | RESET | Resetpin. | |
| 15 | WR/A0 | Second Data lane in 2 data lane serial interface. | |
| 16-17 | NC | Not Connection. | |
| 18 | SCL | SPI interface clock pin. | |
| 19 | SDA | SPI interface input/output pin. | |
| 20 | TE | ||
| 21-28 | NC | Not Connection. | |
| 29 | GND | Ground. | |
| 30 | LEDK | Power supply for backlight cathode input terminals. |
Custom LCD FAQ
1. Are you a factory or a trading company?
we are a high-tech manufacturer specializing in the R&D, production, and sales of LCD and LCM since 2011. At present, we have two factories in Dongguan.
2.What are our main products?
Providing One-stop Liquid Crystal Display and LCM Series, such as COG, COB, ) Customized LCD Series, including Touch Panels
3.What kind of certification do we have?
Our factories have passed ISO9001, 14001 and other certifications.
4. What size LCD display can you provide?
0.96 inch to 21.5 inch TFT LCD display we can provide.
